Supermicro X11SPW-CTF User Manual

13
Chapter 1: Introduction
Note: Table is continued on the next page.
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JPS1 SAS 3.0 Enable/Disable Pins 1-2 (Enabled)
JPSAS1 SAS HDD Enable/Disable Pins 1-2 (Enabled)
JPTG1 LAN Enable/Disable Pins 1-2 (Enabled)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
LED Description Status
LE1 Unit Identier (UID) LED Solid Blue: Unit Identied
LE2 Onboard Power LED Solid Green: Power On
LE3 M.2 LED Blinking Green: Device Working
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
LEDS1 SAS Activity LED
Blinking Green: SAS Active
Solid Red: SAS Error
Connector Description
BT1 Onboard Battery
COM1, COM2 COM Port, COM Header
FAN1 ~ FAN7 System Fan Headers
JD1 Speaker/Power LED Indicator (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External I
2
C Header (for an IPMI card)
JL1 Chassis Intrusion Header
JNVI
2
C1 NVMe I
2
C Header
JOH1 Overheat LED Header
JPI
2
C1 Power System Management Bus (SMB) I
2
C Header
JPWR1 8-pin 12V DC Power Connector for CPU (Required)
JPWR2 24-pin ATX Power Connector
JPWR3 4-pin 12V Power Connector for GPU Card (Requires an extra 12V power at up to 75W)
JRK1 Intel RAID Key Header
JSD1, JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
JUIDB1 Unit Identier (UID) Switch
(IPMI) LAN Dedicated IPMI LAN Port

Supermicro X11SPW-CTF Specifications

General

Brand	Supermicro
Model	X11SPW-CTF
Category	Motherboard
Language	English
