X11SSL-CF/-nF User Manual
Connector Description
JUIDB1 UID (Unit Identication) Switch
LAN1/LAN2 Gigabit (RJ45) LAN Ports
PCI-E (CPU) Slot 6 PCI-Express 3.0 x8 in x16 Slot
PCI-E (PCH) Slot 5 PCI-Express 3.0 x4 in x8 Slot
PCI-E (PCH) Slot 4 PCI-Express 3.0 x1 Slot
SP1 Internal Speaker/Buzzer
USB 0/1 Back Panel USB 2.0 Ports
USB 2/3, USB 4/5 Front Accessible USB 2.0 Headers
USB 6/7 Back Panel USB 3.0 Ports
USB 8 USB 3.0 Type-A Header
USB 9/10 Front Accessible USB 3.0 Header
VGA Back Panel VGA Port
