Chapter 1: Introduction
Note: The table above is continued on the next page.
Motherboard Features
CPU
• Intel® Xeon® E3-1200 v6/v5, 7th/6th Gen Core™ i3, Pentium, and Celeron series processor in an LGA 1151 (H4) socket.
80W max TDP.
Memory
• Four (4) 288-pin DIMM slots support up to 64 GB of SDRAM 72-bit DDR4 unbuffered ECC 2400/2133/1866/1600/1333MHz
memory.
DIMM Size
• 16GB, 8GB, and 4GB, up to 64GB at 1.2V
Note 1: Memory speed support depends on the processors used in the system.
Note 2: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
• Intel® PCH C232
Expansion Slots
• One (1) PCI Express 3.0 x1 slot (PCH Slot 4)
• One (1) PCI Express 3.0 x4 in x8 (PCH Slot 5)
• One (1) PCI Express 3.0 x8 in x16 slot (CPU Slot 6)
Network
• Intel® i210 AT Gigabit Ethernet Controllers for LAN1/LAN2
Baseboard Management Controller (BMC)
• Aspeed 2400 Baseboard Management Controller (BMC) supports IPMI 2.0
Graphics
• Graphics controller via Aspeed AST2400 BMC
I/O Devices
• Serial (COM) Port
• One (1) serial port on the rear I/O panel (COM1)
• One (1) front accessible serial port header (COM2)
• SATA 3.0
• Six (6) I-SATA 3.0 ports (I-SATA 0-5)
• Two (2) SuperDOM connectors (I-SATA0 & I-SATA1)
• RAID • 0, 1, 5, 10
• Mini-SAS HD (X11SSL-CF only) • Two (2) mini-SAS HD connections
• RAID • 0, 1, and 10
• NVMe (X11SSL-nF only) • Two (2) NVMe SSD ports
Motherboard Features
