X11SSL-CF/-nF User Manual
Note: The table above is continued on the next page.
Motherboard Features
Peripheral Devices
• Two (2) USB 2.0 ports on the rear I/O panel (USB 0/1)
• Two (2) front accessible USB 2.0 headers (USB 2/3, USB 4/5)
• Two (2) USB 3.0 ports on the rear I/O panel (USB 6/7)
• One (1) Type-A USB 3.0 header (USB 8)
• One (1) front accessible USB 3.0 header (USB 9/10)
BIOS
• 128Mb AMI BIOS® SPI Flash BIOS
• Dual boot block, Riser Card auto-detection support, Plug and Play (PnP), DMI 3.0, ACPI 4.0+, USB Keyboard and SMBIOS
2.7+, and BIOS rescue hot-key
Power Management
• ACPI Power Management
• Keyboard Wakeup from Soft-Off
• CPU fan auto-off in sleep mode
• Main Switch Override Mechanism
• Wake-On-LAN (WOL)
• Power-on mode for AC power recovery
• Server Platform Service
System Health Monitoring
• Onboard voltage monitors for: CPU cores, +3.3V, +5V, +12V, +5V Stdby, VBAT, HT, memory, and PCH temperature.
• CPU 3-phase switching voltage regulator
• CPU/System overheat control
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) support
Fan Control
• Fan status monitoring with rmware 4-pin fan speed control via IPMI interface
• Fan speed control
System Management
• PECI (Platform Environment Conguration Interface) 2.0 support
• IPMI 2.0 with KVM support
• SuperDoctor® 5, Watch Dog, NMI
• Chassis Intrusion header and detection
LED Indicators
• CPU/overheating
• Power indicator
• Fan failed
• UID/remote UID
• HDD activity
• LAN activity
