Supermicro X9DRG-OF-CPU User Manual

Chapter 1: Overview
1-11
LED Description State Status
LE10 CPU1 Slot10 Link Status Indicator
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE11 CPU1 Slot11 Link Status Indicator
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE12
CPU2 Port2 Link Status Indicator
(Uptream port status of CPU2 Slot 3/4)
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE13 CPU2 Slot3 Link Status Indicator
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE14 CPU2 Slot4 Link Status Indicator
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE15
CPU2 Port3 Link Status Indicator
(Uptream port status of CPU2 Slot 1/2)
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE16 CPU2 Slot1 Link Status Indicator
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s
LE17 CPU2 Slot2 Link Status Indicator
Off
1HZ Green Blinking
2HZ Green Blinking
Static Green On
Link is down
2.5GT/s
5GT/s
8GT/s

Supermicro X9DRG-OF-CPU Specifications

General

Brand	Supermicro
Model	X9DRG-OF-CPU
Category	Motherboard
Language	English
