X9DRG-O(T)F-CPU/X9DRG-O-PCIE Platform User’s Manual
Motherboard Features
CPU
• Dual Intel
®
E5-2600(V2) Series (Socket R LGA 2011)
processors; each processor supports two full-width
Intel QuickPath Interconnect (QPI) links (with Data
Transfer Rate of up to 8.0 GT/s per QPI).
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory
• Integrated memory controller supports up to 1.5 TB of
LRDIMM, 768 GB of RDIMM, or 128 GB of UDIMM
ECC/Non-ECC DDR3 800/1066/1333/1600/1866
MHz 240-pin 4-channel memory modules in 24 DIMM
slots.
Note 1: 1866 MHz memory speed is dependent
on Intel E5-2600v2 CPUs.
Note 2: For the latest memory updates, please
refer to the Tested Memory List posted on our
website (http://www.supermicro.com/products/
motherboard).
Chipset
• Intel
®
C602 PCH
Expansion
• Ten (10) PCI-E 2.0/3.0 slots: eight (8) x16, two (2) x8
(all in x16 slot)
• One (1) PCI-E 2.0 x4 in x16 slot (from PCH)
Slots
Graphics
• Nuvoton BMC Video Controller (Matrox G200)
Network
• One Intel I350 Gigabit (10/100/1000 Mb/s) Ethernet
Dual-Channel Controller for LAN 1/LAN 2 ports (for
X9DRG-OF-CPU)
• One Intel X540 Dual-Channel Controller for 10G-
based-T LAN 1/LAN 2 ports (for X9DRG-OTF-CPU)
