PCIE Card Block Diagram

1-2 Processor and Chipset Overview

Built upon the functionality and the capability of Intel

E5-2600 Series Proces-

sors (Socket R) and the C602 chipset, the X9DRG-O(T)F-CPU/X9DRG-O-PCIE

Platform provides the performance and feature sets required for dual_processor-

based 4U GPU server platforms.

With support of Intel QuickPath interconnect (QPI) Technology, the X9DRG-O(T)

F-CPU/X9DRG-O-PCIE Platform offers point-to-point serial interconnect interface

with a transfer speed of up to 8.0 GT/s, providing superb system performance.

The PCH chipset provides extensive IO support, including the following functions

and capabilities:

•PCI-Express Rev. 2.0 support

•ACPI Power Management Logic Support Rev. 3.0b or Rev. 4.0

•USB host interface backplane and front access support

•Intel Rapid Storage Technology supported

•Intel Virtualization Technology for Directed I/O (Intel VT-d) supported

•Intel Trusted Execution Technology supported

•Serial Peripheral Interface (SPI) Supported

•Digital Media Interface (DMI) supported

•Advanced Host Controller Interface (AHCI) supported

Note: For Intel E5-2600(v2) processor support, BIOS version 3.0 or

above is required.

Supermicro X9DRG-OF-CPU User Manual
