Chapter 1: Overview
1-13
I/O Devices
SATA Connections
• SATA Ports Two (2): SATA 3.0 Ports (I-
SATA0/1)
Eight (8) SATA 2.0 Ports (I-SA-
TA2~5 from AHCI, S-SATA1-4
from SCU)
• RAID RAID 0, 1, 5, 10
IPMI 2.0
• IPMI 2.0 supported by the Nuvoton WPCM450R BMC
Serial (COM) Port
• One (1) Fast UART 16550 Connection: 9-pin RS-232
Header
VGA Port
• One (1) VGA output port
Peripheral
Devices
USB Devices
• Four (4) USB 2.0 ports on the rear I/O panel
• One (1) USB Internal Type A. Two (2) USB 2.0 header,
two ports/header
BIOS
• 16MB SPI AMI BIOS
®
SM Flash BIOS
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0, USB Keyboard,
Plug & Play (PnP) and SMBIOS 2.5
Power
• ACPI/ACPM Power Management
Management
• Main switch override mechanism
• Keyboard Wake-up from Soft-Off
• Power-on mode for AC power recovery
• Intel
®
Intelligent Power Node Manager (Available
when the supporting rmware and the power supply
cable are installed on the motherboard.)
• Management Engine
PC Health
CPU Monitoring
Monitoring
• Onboard voltage monitors for CPU Cores, +1.1V,
+1.5V, +3.3V, +5V, +12V, +3.3V Standby, +5V Stand-
by, VBAT, and Memory Voltages.
• CPU Thermal Design Power (TDP): support up to
150W (See Note 1 on the next page).
To Next Page
