Chapter 2: Installation
2-5
2-3 System Overview
The bare bone system you purchased comes with the X9DRG-O(T)F CPU board,
X9DRG-PCIE Card, and four Riser cards preinstalled in the chassis. You will need
to install the processors, memory modules, and other components on your own.
To install any components on the CPU board, you need to remove the PCIE Card
from the CPU board.
Chassis
PCIE Card
Motherboard
Riser Cards
(4 connected under the PCIE Card)
Note: Images displayed are for illustration only. Your chassis or compo-
nents may look different from those shown in this manual..
