Populating UDIMM (ECC/Non-ECC) Memory Modules
Intel E5-2600(v2) Series Processor UDIMM Memory Support
Ranks
Per
DIMM
& Data
Width
Memory Capacity
Per DIMM
(See the Note below)
Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and
DIMM Per Channel (DPC)
2 Slots Per Channel 3 Slots Per Channel
1DPC 2DPC 1DPC 2DPC
1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v
SRx8
Non-
ECC
1GB 2GB 4GB NA 1066,
1333,
1600,
1866
NA 1066,
1333,
1600
N/A 1066,
1333,
1600,
1866
N/A 1066,
1333,
1600
DRx8
Non-
ECC
2GB 4GB 8GB NA 1066,
1333,
1600,
1866
NA 1066,
1333,
1600
N/A 1066,
1333,
1600,
1866
N/A 1066,
1333,
1600
SRx16
Non-
ECC
512MB 1GB 2GB NA 1066,
1333,
1600,
1866
NA 1066,
1333,
1600
N/A 1066,
1333,
1600,
1866
N/A 1066,
1333,
1600
SRx8
ECC
1GB 2GB 4GB 1066,
1333
1066,
1333,
1600,
1866
1066,
1333
1066,
1333,
1600
1066,
1333
1066,
1333,
1600,
1866
1066,
1333
1066,
1333,
1600
DRx8
ECC
2GB 4GB 8GB 1066,
1333
1066,
1333,
1600,
1866
1066,
1333
1066,
1333,
1600
1066,
1333
1066,
1333,
1600,
1866
1066,
1333
1066,
1333,
1600
Note: For detailed information on memory support and updates, please refer to the SMC Recommended
Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.
Populating UDIMM (ECC/Non-ECC) Memory Modules
Intel E5-2600 Series Processor UDIMM Memory Support
Ranks
Per
DIMM
& Data
Width
Memory Capacity
Per DIMM
(See the Note below)
Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and
DIMM Per Channel (DPC)
2 Slots Per Channel 3 Slots Per Channel
1DPC 2DPC 1DPC 2DPC
1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5v
SRx8
Non-
ECC
1GB 2GB 4GB NA 1066,
1333
NA 1066,
1333
N/A 1066,
1333,
N/A 1066,
1333
DRx8
Non-
ECC
2GB 4GB 8GB NA 1066,
1333
NA 1066,
1333
N/A 1066,
1333,
N/A 1066,
1333
SRx16
Non-
ECC
512MB 1GB 2GB NA 1066,
1333
NA 1066,
1333
N/A 1066,
1333
N/A 1066,
1333
SRx8
ECC
1GB 2GB 4GB 1066,
1333
1066,
1333
1066 1066,
1333
1066 1066,
1333,
1066,
1333
1066,
1333
DRx8
ECC
2GB 4GB 8GB 1066,
1333
1066,
1333
1066 1066,
1333
1066 1066,
1333,
1066,
1333
1066,
1333
Note: For detailed information on memory support and updates, please refer to the SMC Recommended
Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.
Notes: 1866 MHz memory speed is dependent on Intel E5-2600v2 CPUs.
For Intel E5-2600(v2) processor support, BIOS version 3.0 or above is
required.
