Chapter 4: AMI BIOS
4-13
•Minimum Delay Time
•CAS to RAS (tRCDmin)
•Row Precharge (tRPmin)
•Active to Precharege (tRASmin)
Memory Frequency Limiter
This feature sets the limit of memory frequency for DIMM modules installed on
the the motherboard. The options are 1067 (MHz), 1333 (MHz), 1600 (MHz),
and Auto.
Max TOLUD (Top of Low Usable DRAM)
This feature sets the maximum TOLUD value, which species the "Top of Low
Usable DRAM" memory space to be used by internal graphics devices, GTT
Stolen Memory, and TSEG, respectively, if these devices are enabled. The op-
tions are Enabled and Dynamic, 1 GB, 1.25 GB, 1.5 GB, 1.75 GB,. 2 GB, 2.25
GB, 2.5 GB, 2.75 GB, 3 GB and 3.25 GB.
Note: TSEG is a block of memory that is only accessible by the processor
while operating in SMM mode.
Memory Scrambler
This feature enables or disables memory scrambler support for memory error
correction. The settings are Enabled and Disabled.
PCH-IO Conguration
This item displays the information for PCH-IO Chip.
•Intel PCH Rev ID
•USB Conguration
•USB Devices
EHCI1
Select Enabled to enable EHCI (Enhanced Host Controller Interface) Controller 1
for USB 2.0 support. One EHCI controller must always be enabled. The settings
are Enabled and Disabled.
EHCI2
