iii
Preface
Preface
This manual is written for system integrators, PC technicians and
knowledgeable PC users. It provides information for the installation and use of the
X10SLM-F/X10SLL-F/X10SLL-SF/X10SLL-S motherboard.
About This Motherboard
The X10SLM-F/X10SLL-F/X10SLL-SF/X10SLL-S supports Intel® Xeon®
E3-1200 v3 and 4th Gen Core™ i3, Pentium and Celeron processors in an LGA
1150 (H3) socket. With the Intel® C224/C222 Express chipset built in, the X10SLM-
F_X10SLL-(F/SF/S) motherboard supports Intel® Rapid Storage Technology,
offering great system enhancement to entry server/data storage/cloud computing
platforms. Please refer to our website (http://www.supermicro.com/products/) for
processor and memory support updates. This product is intended to be installed
and serviced by professional technicians.
Manual Organization
Chapter 1 describes the features, specications and performance of the mother-
board, and provides detailed information on the Intel C224/C222 Express chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-
stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble-
shooting procedures for video, memory and system setup stored in the CMOS.
Chapter 4 includes an introduction to the BIOS, and provides detailed information
on running the CMOS Setup utility.
Appendix A provides BIOS Error Beep Codes.
Appendix B lists software program installation instructions.
Appendix C contains UEFI BIOS Recovery instructions.
Appendix D provides instructions on how to recover the system BIOS using the
Dual Boot Block scheme.
