X8DAL-3/X8DAL-i Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JI
2
C1/JI
2
C2 SMB to PCI/PCI-E Slots Open/Open (Disabled)
JPAC1 Audio Enabled Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/2 Enable Pins 1-2 (Enabled)
JPS1 SAS Enable Pins 1-2 (Enabled) (X8DAL-3)
JPUSB1 Backpanel USB Wake-Up Pins 1-2 (Enabled)
JPUSB2 Front Access USB Wake-Up Pins 2-3 (Disabled)
JWD Watch Dog Pins 1-2 (Reset)
Connector Description
Audio/CD1/JC1 Audio Input_Output_Mic/CD-ROM/HD Audio Headers
COM1/COM2 COM1/COM2 Serial Port/Header
FAN 1-6 System/CPU Fan Headers (Fans 1~2: CPU Fans)
JD1 PWR LED/Speaker Header (Pins 4~7: Speaker)
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPI
2
C Power Supply SMBbus I
2
C Header
JPW1, JPW2/JPW3 24-pin ATX PWR, 8-pin Secondary PWR (See Page 1-4)
LAN1/LAN2 G-LAN (RJ45) Ports
SAS 0~7 SAS Ports 0~7 (X8DAL-3 only)
I-SATA0 ~ I-SATA5 (Intel South Bridge) SATA Ports
SP1 Speaker/Internal Buzzer
3-SGPIO-1/3-SGPIO-2 Serial General Purpose I/O Headers for SAS (X8DAL-3)
T-SGPIO-1/T-SGPIO-2 Serial General Purpose I/O Headers for SATA
USB 0~3 Backplane Universal Serial Bus (USB) Ports
USB 6/7, 8/9 Front Panel USB Connections
LED Description
LE1 Onboard Standby LED Indicator
LES2 SAS Heartbeat LED (X8DAL-3)
