Chapter 1: Introduction
1-7
System overheat/Fan Fail LED Indicator and control•
Chassis intrusion detection/header•
System resource alert via Supero Doctor III•
ACPI Features
Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI/ACPM Power Management•
Onboard I/O
Intel ICH10R supports six SATA2 ports (with RAID0, RAID1, RAID10, RAID5 •
supported in the Windows OS Environment, and RAID0, RAID1, RAID10 sup-
ported in the Linux platforms) (Note 1)
LSI 1068E supports eight SAS ports with RAID 5 support optional w/AOC-
•
ibutton68 (For X8DAL-3) (Note 2)
Dual 82574LGigabit Ethernet controllers support two Giga-bit LAN ports
•
HD ALC883 Audio Controller supports High Defi nition 7.1 Audio with Line-in, •
Line-out and Microphone
One COM port and one Serial Header
•
PS/2 mouse and PS/2 keyboard ports•
Up to Eight USB 2.0 connections (4 Backpanel USB Ports, and 2 Headers w/4 •
connections supported)
Super I/O: Winbond W83627DHG-P
•
Other
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers•
Dimensions
Ext. ATX 12.00" (L) x 10.00" (W) (304.80 mm x 254.20 mm)•
Note 1: For more information on SATA HostRAID confi guration, please
refer to the Intel SATA HostRAID User's Guide posted on our website @
http://www.supermicro.com/support/manuals/.
Note 2: For more information on LSI SAS RAID confi guration, please refer
to the LSI MegaRAID User's Guide posted on our website @ http://www.
supermicro.com/support/manuals/.
