Chapter 1: Introduction
1-5
Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear (See Section 5-10)
JI
2
C1/JI
2
C2 SMB to PCI Slots 2-3 (Disabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/2 & LAN 3/4 Enable Pins 1-2 (Enabled) (JP2: for LN4 models)
JPS1 SAS Enable Pins 1-2 (Enabled) (Note 5 P. 1-4)
JPS2 SAS RAID Enable Closed (SR RAID Enabled) (Note5 P1-4)
JWD Watch Dog Pins 1-2 (Reset)
Connector Description
COM1/COM2 COM1/COM2 Serial Port/Header
FAN 1-8 System/CPU Fan Headers (Fans 7~8: CPU Fans)
Floppy Floppy Disk Drive Connector
I-Button I-Button for data storage (optional for X8DT3/-F/LN4F only)
J5 IPMB I
2
C Header (for an IPMI card)
J6 Power Supply SMBbus I
2
C Header
JD1 PWR LED/Speaker Header (Pins 4~7: Speaker)
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPW1/JPW2, JPW3 8-pin Secondary PWR, 24-pin ATX PWR (See Warning)
JWOL Wake-On-LAN Header
LAN1/2, 3/4, Dedicated
LAN
Gigabit Ethernet (RJ45) Ports (See Note 5 on P. 1-4)
I-SATA0 ~ I-SATA5 (Intel South Bridge) SATA Ports
SAS 0~3, 4~7 SAS Ports 0~3, 4~7 (X8DT3/-F/-LN4F only)
T-SGPIO-1/T-SGPIO-2 Serial General Purpose Input/Output Headers
USB 0/1, 2,3, 4/5, 6/7 Universal Serial Bus (USB) Ports
VGA VGA Connector
LED Description
D1 BMC Heartbeat LED Indicator
LE1 Onboard Standby LED Indicator
LES1/LES2 SAS LEDs (LES1: SAS Heartbeat, LES2: SAS Activity LEDs)
Warning: To prevent damage to the power supply or motherboard, please use a
power supply that contains a 24-pin and two 8-pin power connectors. Be sure to
connect these connectors to the 24-pin (JPW3) and the two 8-pin (JPW1,JPW2)
power connectors on the motherboard. Failure in doing so will void the manufacturer
warranty on your power supply and motherboard.
