UEFI BIOS Recovery
3
5.
When
the
screen
as
shown
above
displays,
using
the
arrow
key
,
select
the
item-
"Proceed
with
ash
update"
and
press
the
<Enter>
key
.
Y
ou
will
see
the
progress of BIOS Recovery as shown in the screen below
.
Note:
Do not interrupt
the
process
of
BIOS
ashing
until
it
is
completed.
6.
After
the
process
of
BIOS
Recovery
is
complete,
press
any
key
to reboot the system.
7.
Using
a
different
system,
extract
the
BIOS
package
into
a
bootable
USB
ash
drive.
106
