Chapter 2: Installation
2-23
1.
VGA
Video Con
nector
A
Video
(VGA)
connector
is
located
next
to
the
COM
Port
on
the
I/O
backpanel.
This
connector
is
used
to
provide
video
and
CR
T
display
.
Refer to the board layout below for
the location.
VGA/CRT Pin
Denitions
Pin# Denition
Pin# Denition
1
Red
10
Ground
2
Green
11
NC
3
Blue
12
MS1: SDA
(DDC Data)
4
NC
13
HSYNC
5
Ground
14
VSYSNC
6
Ground
15
MS3: SCL
(DDC CLK)
7
Ground
16
Case
8
Ground
17
Case
9
5V
NC= No Connection
1
1
48
50
