Chapter 2: Installation
2-21
Ethernet Ports
T
wo
Ethernet
ports
(LAN1/LAN2)
are
located
next
to
the
VGA
port
on
the
I/O
Backpanel.
In
addition,
an
IPMI
Dedicated
LAN
is
also
located
above
USB
0/1
ports
on
the
X9SCM-IIF/
X9SCL-IIF
to
provide
a
dedicated
net
-
work
connection
for
IPMI
2.0.
These
ports accept RJ45 type cables.
Notes
Please refer to the LED In
-
dicator Section for
LAN LED
information.
1.
LAN1
2.
LAN2
3.IPMI
Dedicated
LAN
1
2
3
LAN Ports
Pin Denition
Pin# Denition
1
TD0-
10
SGND
2
TD0+
11
P3V3SB
3
TD1-
12
Act LED
4
TD1+
13
Link 100 LED
(Green, +3V3SB)
5
TD2-
14
Link 1000 LED
(Y
ellow
, +3V3SB)
6
TD2+
15
Ground
7
TD3-
16
Ground
8
TD3+
17
Ground
9
P2V5SB
88
Ground
(NC: No Connection)
