Motherboard Features
CPU Single Intel® E3-1200 v2 family series, 2nd generation
Intel Core® i3, Pentium®, Celeron® processor in an LGA
1155 socket
Memory Four (4) SDRAM DIMM slots support up to 32 GB of DDR3
Unbuffered, ECC 1333/1066/1600 memory
Supports dual-channel memory bus
DIMM sizes
UDIMM 1 GB, 2 GB, 4GB and 8GB
Chipset Intel® C204 Express (X9SCM-II Series)
Intel® C202 Express (X9SCL-II Series)
Expansion Slots X9SCM-IIF: Four (4) PCI-E 2.0 x4 (in x8) slots
X9SCL-IIF: Three (3) PCI-E 2.0 x4 (in x8) slots
Integrated Graphics Matrox® G200eW
Network Connections Two (2) Intel 82574L Gigabit Ethernet controllers, one
each for LAN 1 and LAN 2.
Two (2) RJ-45 Rear IO Panel Connectors with Link and
Activity LEDs
Single Realtek RTL8201FN to support IPMI 2.0 LAN
I/O Devices SATA Connections
SATA-III Ports (6Gb/s) •Two (2) (I-SATA 0/1)
•RAID 0, 1
SATA-II Ports (3Gb/s) •Four (4) (I-SATA 2~5)
•RST 11.0, RAID 0, 1, 5 & 10
Onboard IPMI
IPMI 2.0 supported by the WPCM450 Server BMC
USB 2.0 Devices
Two (2) USB ports on the rear IO panel (USB 0/1)
Six (6) USB header connectors for front access (USB 2/3,
USB 4/5, USB 12/13)
One (1) Type A USB internal connector (USB 11)
Keyboard/Mouse
PS/2 Keyboard/Mouse ports on the I/O backpanel
Serial (COM) Ports
Two (2) Fast UART 16550 connections: one 9-pin RS-232
port (Backpanel COM1 port) and one header (FP COM2)
Super I/O
Winbond Super I/O NCT6776F
