X9SCM-IIF/X9SCL-IIF Series User’s Manual
X9SCM-IIF/X9SCL-IIF Headers/Connectors
Connector Label Description
JLAN1/JLAN2 Gigabit (RJ45) Ports (LAN1/2)
IPMI IPMI LAN Port
FAN1~4, FANA System Fan Headers
VGA On board Video Port
COM1, COM2 Back panel COM1 port, COM2 header
KB/MOUSE Back panel Keyboard and Mouse port
JTPM Trusted Platform Module (TPM) Header
USB 0/1 Back panel USB 2.0 ports 0/1
JUSB2~5, 12/13 Intermal USB 2.0 headers
JUSB11 Internal USB 2.0 Type "A" connector
JPW2 +12V 8-pin CPU power Connector (Required)
JPW1 24-pin ATX Main Power Connector (Required)
JPI2C PWR supply (I2C) System Management Bus
JLED 3-pin Power LED header
JF1 Front Panel Control Header
JSPK Speaker header (Pins 3/4: Internal, 1~4:External)
SPKR1 Internal speaker/buzzer
T-SGPIO-1/2 Serial Link General Purpose IO 1/2 Headers (5V Gen1/Gen 2)
JL1 Chassis Intrusion Header
JSD1 SATA DOM (Disk On Module) Power Connector
I-SATA 0/1 SATA 3.0 ports 0/1 (6Gb/s)
I-SATA 2~5 SATA 2.0 ports 2~5 (3Gb/s)
JSTBY1 Stand-by Power header
X9SCM-IIF/X9SCL-IIF LED Indicators
LED Label Description Color/State Status
LE7 IPMI Heartbeat LED Green: Blinking IPMI Active
LE2 Standby Power LED Green: On, Steady Power is connected
LE4 Power LED Green: On, Steady System is on/running
LE3 Memory Support Green: Blinking Unsupported memory is installed
