Chapter 1: Introduction
1-7
Two (2) USB 3.0 (5Gb/s) headers for front panel access
Two (2) USB 3.0 (5Gb/s) ports on the rear I/O panel
Keyboard/Mouse
One (1) PS/2 KB/Mouse combo port on the I/O backpanel
Serial (COM) Ports
Two (2) Fast UART 16550 connections on two headers
(COM1 & COM2)
Super I/O
Winbond Super I/O NCT6776F
BIOS 32 Mb SPI AMI BIOS
®
SM Flash BIOS
Play and Plug APM 1.2, DMI 2.3, PCI 2.2, ACPI 1.0/2.0,
USB Keyboard and SMBIOS 2.3
Power Conguration ACPI/ACPM Power Management
Wake On LAN (WOL) Header
Keyboard Wake-up from Soft-Off
CPU Fan Auto-off in Sleep Mode
Power-on mode for AC power recovery
PC Health Monitoring CPU & Chassis Monitoring
Onboard voltage monitors for CPU core, +1.8V, +3.3V,
+5V, +/-12V, +3.3V Stdby, +5V Stdby, VBAT, HT, Memory,
Chipset
CPU 6-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
CPU & Chassis Environment Monitor
Fan Control
Fan status monitoring with rmware 4-pin (Pulse Width
Modulation) fan speed control
Low noise fan speed control
System Management System resource alert via Supero Doctor III
SuperoDoctor III, Watch Dog, NMI, PECI 2.0
Chassis Intrusion header and detection
CD Utilities BIOS ash upgrade utility
Drivers and software for Intel® C204 chipset utilities
Other ROHS 6/6 (Full Compliance, Lead Free)
TPM 1.2 on board & Disk on Module Power Connector
FCC B, EuP Lot 6, WHQL
Dimensions ATX form factor (12" x 9.6")
