4-14
X9SRA Motherboard Series User’s Manual
Maximum Read Request
This feature selects the setting for the PCIE maximum Read Request size. The
options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and
4096 Bytes.
ASPM Support
Set this item to the desired ASPM (Active State Power Management) level. The
options are Disabled, Auto and Force L0s..
Slot 1 PCI-E 2.0 x4 OPROM,
Slot 2 PCI-E 3.0 x4 OPROM,
Slot 3 PCI 33MHz OPROM,
Slot 4 PCI-E 3.0 x16 OPROM,
Slot 5 PCI-E 2.0 x1 OPROM,
Slot 6 PCI-E 3.0 x16 OPROM
Use this feature to enable or disable PCI-E or PCI slot Option ROMs. The options
are Disabled and Enabled.
Onboard LAN Option ROM Select
This feature selects whether to load the iSCSI or PXE onboard LAN option ROM.
The options are iSCSI and PXE.
Load Onboard LAN1 Option ROM / Load Onboard LAN2 Option ROM
This feature is to enable or disable the onboard option ROMs. The options are Dis-
abled and Enabled. The default for LAN 1 is Enabled. Default for LAN 2 is Disabled.
Load Onboard SAS Option ROM
This feature selects whether to load the SAS option ROM. The options Enabled
and Disabled.
VGA Priority
This option allows the user to specify which graphics controller to be used as the
primary boot device. The options are Onboard and Offboard.
Super IO Device Conguration
Serial Port 1 Conguration / Serial Port 2 Conguration
Serial Port 1 / Serial Port 2
Select Enabled to enable the onboard serial port. The options are Enabled
and Disabled.
