Supertech CS-164 User Manual

8. MODE BUTTON (MODE)
By pressing this key, user can select RADIO mode or CD/
MP3/SD/MMC/USB PLAYER mode.
9. BAND BUTTON(BND)
Each band is toggled cyclically by pressing this key FM1 -FM2
-FM3- AM1 - AM2.
10. 11.SKIP FORWARD( ) / SKIP BACKWARD ( )
CD/MP3/SD/MMC/USB PALYER MODE
When press short, they are operated as TRACK UP/DOWN
mode.
When press longer than 1 secretary, they are operated as
CUE or REVIEW mode.
12. LCD DISPLAY
The liquid Crystal Display w ill display the current state of the
unit.
13. PANEL RELEASE BUTTON
Press this button and the left - hand part of the panel will be
released.
CD CONTROL LOCATION OF PARTS
10.11. SKIP TRACK/SEARCH BUTTON
Forward and Backward track search (or changing song s)
Press the SKIP button(TUN or TUN ) during play to go
to the desired track (song).
TUN ...backward TUN ...forward
When the desired music section of the disc is found, release
the button. Normal play will resume. When CD/MP3 play is
finishe d, CD/MP3 mode automatically changes to radio mode.

Supertech CS-164 Specifications

FM Tuner

frequency range	87.5-108.0 MHz
usable sensitivity	2 V at s/n 30 dB
intermediate frequency	10.7 MHz

MW Tuner

frequency range	520-1620 KHz
usable sensitivity	40 dB at S/N 20 dB
intermediate frequency	455 KHz

CD/MP3 Player Section

signal to noise ratio	>60 dB
frequency response	20 Hz-18 KHz

Reamplified Lineout

output	600 mV (MAX)
impedance	10 Kohm

General

power supply voltage	DC 13.2 Volts Negative Ground
maximum current consumption	6 A
maximum output power	40 W X4CH
