Supertech CS-164 User Manual

LOCATIONS OF CONTROLS
1. Power on/off button (PWR)
2. Select button (SEL)
3. Volume up/down button
4.AF (altern ative frequencies)
5. TA Traffic announcement
6. Manual tuning knob
7. Display button (DSP)
8. Mode button MODE
9. Band button (BND)
10.Skip forward( )
11.Skip backward ( )
12.LCD display
13.Release button
14.CD slot
15.CD eject button
16.Play/pause button
17.Intro button (INT)
18.Repeat button (RPT)
19.Random button (RND)
20.Skip 10 tracks up
21.Skip 10 tra cks down
22.Reset button (not in common use)
23.SD/MMC card jack
24.USB slot

Supertech CS-164 Specifications

FM Tuner

frequency range	87.5-108.0 MHz
usable sensitivity	2 V at s/n 30 dB
intermediate frequency	10.7 MHz

MW Tuner

frequency range	520-1620 KHz
usable sensitivity	40 dB at S/N 20 dB
intermediate frequency	455 KHz

CD/MP3 Player Section

signal to noise ratio	>60 dB
frequency response	20 Hz-18 KHz

Reamplified Lineout

output	600 mV (MAX)
impedance	10 Kohm

General

power supply voltage	DC 13.2 Volts Negative Ground
maximum current consumption	6 A
maximum output power	40 W X4CH
