4.5.2 ELECTRICAL PANEL
2 x 125v 20 amp
duplex receptacles
(5-20R)
20 amp pop
up breaker
2 x 125v 20 amp
GFCI duplex
receptacles
(GFCI 5-20R)
2 x 20 amp pop
up breaker
2 x 125v 20 amp
GFCI duplex
receptacles
(GFCI 5-20R)
2 x 20 amp pop
up breaker
125v 20 amp
duplex receptacle
(5-20R)
2 x 20 amp pop
up breaker
125/250v L14-30R
receptacle
(20 amp max.)
SM5000GFI
Two GFCI duplex receptacles for 120v power,
each protected by a 20 amp pop up breaker.
SM5000CH
One four prong twist lock outlet is used to provide
120/240 Volt, protected by two 20 amp pop up break-
ers. One split duplex outlet for 120v, protected by a
20 Amp pop up breaker for each outlet .
SM3000SU & SM3000GFI
Two duplex GFCI outlets provide 120 v, each
protected by a 20 Amp pop up breaker.
Two duplex receptacles provide 120v, protected
by one 20 amp pop up breaker.
SM2500CH
Two duplex receptacles provide 120v, each pro-
tected by a 20 amp pop up breaker.
SM3000CH
2 x 125v 20 amp
duplex receptacles
(5-20R)
2 x 20 amp pop
up breaker
