SURUGA SEIKI H410 Series User Manual

7 Speci¿cation
7-3
Item Speci¿cation
External
communication
RS232C D-sub 9-pin connector (use the cross cable)
Baud rate: 9600, 19200, 38400, 57800, and 115200
Measurement data output and control command input/output
Ethernet RJ-45 connector
Transmission method: 1000Base-T and 100Base-TX
Communication method: TCP/IP, FTP and socket communication
Measurement data output and control command input/output
Display LED (Green/Red)
Environment
condition
Ambient temperature
for use
0 to 40C
Ambient humidity for
use
35 to 85 RH
Storing temperature -10 to +60C
Vibration resistance Frequency range: 10 to 500 Hz
Maximum acceleration: 2 G and X/Y/Z axis
External dimensions 60 mm x 150 mm x 120 mm (W x H x D)
Weight Approx. 900 g

Sensor Head
Item Speci¿cation
Model No. H410-175R
Angle measurement range 1.75 degrees: Measurement distance < 120 mm
1.00 degrees: Measurement distance < 200 mm
0.50 degrees: Measurement distance < 300 mm
Light source Wave length Red semiconductor laser 655 nm
Output 0.39 mW laser class 1
Emission position 200.5 mm or less (Distance from the reference surface 1)
150.5 mm or less (Distance from the reference surface 2)
Emission angle 0.05 degrees or less
Spot diameter Approx.
כ
1.0 mm
Measurement reproducibility 3.6 seconds
Linearity  2 of F.S.
F.S.=
 1.75 degrees (When measurement distance is < 120 mm)
 1.00 degrees (When measurement distance is < 200mm)
 0.50 degrees (When measurement distance is < 300mm)
Measurement sampling cycle 20 msec to
Display LED (Green/Red)
Environment
condition
Ambient temperature
for use
0 to 40C
Ambient humidity for
use
35 to 85 RH
Performance guarantee
temperature
23  5C
Storing temperature -10 to +60C
Vibration resistance Frequency range: 10 to 500 Hz
Maximum acceleration: 2 G and X/Y/Z axis
External dimensions 40 mm x 60 mm x 40 mm (W x H x D)
Weight Approx. 160 g
