SURUGA SEIKI H410 Series User Manual

1 Preparations
1-2
System Con¿gurations
In addition to take measurement by itself, this product can be used according to purposes by combining
with commercially available devices.
PC
Control and measurement values
can be loaded from PC with
RS232C communication and
Ethernet communication.
Touch panel monitor
Measurement display and input
operation can be performed.
DC 24 V power source
PLC
Programmable Logic Controller
Measurement control and measurement
values can be loaded.
IPU
(ImageProcessingUnit)
SensorHead
RS232C
Cross cable
Monitor
Cable
Ethernet cable
Touch panel
Connection cable
Monitor power source
Connection cable
Sensor head
connection cable
I/O cable
