Survision Micropak 3 - Attachment of the Support Bracket to the Wall Using the Fixation Kit with Angular Displacement Provided by SURVISION

15
2.2.2 Attachment of the support bracket to the wall using the xation kit with
angular displacement provided by SURVISION
Step 1
Step 2
1.2 - First attach the three screws (but
not the one on the curved ruler)
1.3 - Then t the screw on the curved ruler
to set the required tilt (20° in our example)
Fit the cradle and the camera to the
bracket using the two diameter M6
screws.
1.1 - Fit the cradle to the front of the
sunvisor, on the lower part, using the
screws of diametre M5
