Technical data
Relative humidity 0 ... 90% rH
Casing material PC + ABS
Charging time 7 h (if switched on), 4 h (if switched off)
Protection class IP65
Dimensions See dimensional drawing on the page 10
Display 2.8” colour graphic display
Weight 0.7 kg (with measuring chamber), 0.45 kg
(without measuring chamber)
* At least 0.3 MPa is needed for the measuring chamber supplied with
the instrument. For low-pressure measuring below 0.3 MPa, choose the
optional bypass measuring chamber A699 3501.
5.2 Electrical data
Power supply USB charger: 5 V, 2 A
5.3 Accuracy
Accuracy Dew point: ± 2°C Td @ -50°C
Temperature:± 0.3°C
Pressure:± 0.005 MPa
Repeatability ± 0.5°C
Stated accuracy at Ambient/process temperature: 23°C ± 3°C
Ambient humidity: 0 ... 80% rH, no
condensation
Accuracy:
8 S505
