2-22
RIGHT HANDLEBAR
FRONT BRAKE LEVER 1
The front brake is applied by squeezing the
brake lever gently toward the throttle grip.
This motorcycle is equipped with a disk
brake system and excessive pressure is not
required to slow the machine down properly.
The brake light will be lit when the lever is
squeezed inward.
THROTTLE GRIP 2
Engine speed is controlled by the position of
the throttle grip. Turn it towards you to
increase engine speed. Turn it away from
you to decrease engine speed.
ELECTRIC STARTER SWITCH “” 3
Push in the electric starter switch to operate
the starter motor. With the ignition switch in
the “ON” position, the transmission in neu-
tral and push the electric starter switch to
start the engine.
NOTICE
Check if the engine is under the follow-
ing conditions. If the engine is started
under the conditions other than those
mentioned, the serious engine damage
may result. If these conditions are not
indicated on the indicator, consult your
Suzuki dealer for checking.
• When the neutral indicator light comes
on, the gear position indicator should
indicate “0” (Neutral).
• When the neutral indicator light goes off,
the gear position indicator should indi-
cate either “1”, “2”, “3”, “4”, “5” or “6”.
