6-10 CHASSIS
WHEEL BEARING
• Apply grease to the wheel bearings.
X 99000-25010: SUZUKI SUPER GREASE “A”
• First install the left wheel bearing, then install the right wheel
bearing and spacer by using the special tools.
\ 09941-34513: Bearing/Steering race installer set
The sealed cover of the bearing must face outside.
BRAKE DISC
Make sure that the brake disc is clean and free of any greasy
matter.
• Apply THREAD LOCK SUPER “1360” to the disc mounting bolts
and tighten them to the specified torque.
" Brake disc bolt (Front): 23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)
K99000-32130: THREAD LOCK SUPER “1360”
To Next Page
