ENGINE 3-57
• Apply a small quantity of THREAD LOCK to the bearing re-
tainer screws and the shift fork shaft retainer screw and tighten
them.
J99000-32050: THREAD LOCK “1342”
• Tighten the gearshift shaft spring stopper.
" Gearshift shaft spring stopper:
10 N
.
m (1.0 kgf
.
m, 7.4 lb-ft)
CRANKSHAFT
• Install the cam chain tensioner.
• Install the cam chain tensioner cushion so that its arrow is di-
rected to front and rear.
• Apply molybdenum oil solution to each crankshaft journal bear-
ing lightly.
P MOLYBDENUM OIL SOLUTION
• Set the crankshaft to the crankcase with the cam chain.
• Apply molybdenum oil solution to the thrust bearings and in-
sert the right and left-thrust bearings with oil groove facing the
crank web.
P MOLYBDENUM OIL SOLUTION
NOTE:
Right-thrust bearing has green painting.
To Next Page
