CHASSIS 5-23
INSPECTION
KNUCKLE ARM BUSH
Insert the spacer into the bush and inspect for abnormal noise
and smooth rotation while rotating the spacer.
If any defects are found, replace it with a new one.
• Remove the knuckle arm bushes with the special tools.
\ 09923-73210: Bearing remover
09930-30104: Sliding shaft
SUSPENSION ARM
Inspect the suspension arm and suspension arm bush for wear
or damage. If any defects are found, replace it with a new one.
FRONT SHOCK ABSORBER
Inspect the shock absorber body and bush for damage and oil
leakage. If any defects are found, replace it with a new one.
Do not attempt to disassemble the front shock
absorber. It is unserviceable.
