7. TROUBLE SHOOTING
8. SPECIFICATION
Notes:
1. Given specifications may not serve the basis for claims.
2. Sven production is constantly developed. That’s why the specifications may be changed without preliminary notice.
14
Problem Cause Solution
No power. The power plug connected improperly. Reconnect properly.
The power switch doesn`t turn on. Turn on the power switch.
No sound. The volume potentiometer is at minimum
position.
Turn the volume potentiometer properly.
The signal in connected improperly. Connect properly.
Woofer no sound or
volume low.
The signal line connected improperly. Connect the signal line properly.
Volume controls are at minimum position. Adjust the volume controls properly.
Distortion. Volume is too loud. Adjust the volume controls accordingly.
Parameter, unit Value
Output power, W (RMS)
subwoofer
satellite
25
5 х 10
Speaker units
subwoofer
satellite
5"
2,5"
Impedance, Ohm 4
Voltage supply 220 V, 50 Hz
Frequency range, Hz 60–20 000
Dimensions, mm
subwoofer
satellite
210 х 210 х 232
195 х 105 х 70
Weight, kg 5,3
OPERATION MANUAL
