Swegon TAC6 - SAT WIFI Connection

User’s manual TAC6 + MODBUS TCP/IP
8
1.3.2 SAT WIFI connection
The SAT WIFI comes preassembled and no additional wiring is necessary. It includes:
- 1 SAT WIFI component with a label reporting its unique MAC address (6x2 digits) and UFL male connector
(figure 9)
- 1 metallic support for the antenna (figure 11).
- 1 antenna with SMA male connector (figure 8)
- 1 UFL female-SMA female antenna cable to connect the SAT WIFI component to the antenna (figure 10)
Figure 6 – SAT WIFI
Component
Figure 7 - Antenna
Figure 8 – Antenna
support
Figure 9 - UFL-SMA Cable
