40 ©2021 Swellpro Technology Co., Limited
Working current/voltage:
0.3A/7.4V
Micro USB port:
Firmware upgrade/fly log data read
SDK port
Read flight data and send standard command
to flight control
Ethernet interface:
Connect computers and develop software
applications. IP: 192.168.2.220:2222
Wi-Fi Hotspot
IP: 192.168.2.220: 2020
Phone mount kits:
Used to fix a phone or tablet
Screen:
2.68inch, 128x64
Working temperature:
-10℃-40℃
Intelligent Battery (IB1)
Capacity:
6600mAh
Voltage:
14.8V
Type:
4S LiPo
Power:
97.68Wh
Battery weight:
730g (+/-5g)
Size:
153.6*82.4*48.3mm
Working temperatrure:
5℃-40℃
Maximum charging power:
84.5W
Charger
Input voltage
100-240V
Output voltage:
16.8V & 5V
Rated power:
84.5W
1Axis Gimbal Camera (GC1)
Waterproof:
IP67
Axis:
1 axis (pitch)
Pitching angle:
-90°to 0°
Maximum control speed:
Pitching 60°/s
Weight:
Approx. 145g
Size:
71*55*65mm
Image Sensor:
1/2.3" 12M SONY CMOS
Lens:
F4.53mm f/2.65, FOV: 92.6°
ISO range:
100 - 3200
Shutter speed
16 - 1/16000 s
Picture Resolution:
4:3/16:9 12M pixel
Photo shooting mode
A single shot
Burst:
3/5/10 pcs
Interval
1/3/5/10s
Video Resolution:
4K: 3840*2160/30P | 2.7K: 2704*1520/60P |
FHD: 1920*1080 30/60/120p | HD:
1280*720/240p
Max Video Stream:
64mbps
Picture Format:
JPEG / RAW
