SWELLPRO SplashDrone4 - Specifications

©2021 Swellpro Technology Co., Limited 39
Specifications
Aircraft
Waterproof Level:
IP67（can floating on water）
Drone Weight（include battery and props）：
2.38kg
Size：
379.2*379.2*39.3mm(Propellers excluded)
Axis Diameter:
450mm
Max Ascend Speed:
4m/s
Max Descend Speed:
3m/s
Max Flight Speed:
18m/s（ATTI), 10m/s（GPS)
Maximum tilt Angle：
25°（ATTI)
Maximum angular velocity of rotation：
150°/s
Max Flight Altitude:
4000m
Maximum resistant wind speed:
72km/h; 45mph;
Max Flight Time (per charge):
30mins without any mount kits（mount GC3-
S approx. 25mins ， mount 1.5Kg
approx.15mins）
Max Payload Capacity:
2.0Kg
Motor：
#2814 800KV
ESC：
40A
Propellers：
#1242 carbon fiber quick-fit propellers
Working Temperature：
-10℃ ~ 40℃
Satellite positioning module：
GPS/GLONASS
Hovering Precision:
±0.5m（vertical）±0.5m（level）
Transparent serial port：
Connect to a third-party device and transfer
the data of the third-party device to the remote
control
UART:
It provides an air interface from TTL serial
port to TCP, which can connect different
devices supporting 115200 baud rate
Wi-Fi Hotspot (IP: 192.168.1.101:2222)
The only Wi Fi hotspot matched with the
aircraft is used to connect various mounted
devices. After learning about the hotspot
through the aircraft number or app, fix the IP
and port, and then any data of Wi Fi connected
devices in the air can be accessed and
manipulated by the ground computer or other
clients through TCP or UDP through the
aircraft.
Power supply port
12V/2A | 5V/2A
Remote control (MRC)
Waterproof Level:
IP66
Frequency：
5.8GHz | 2.4GHz
Real-time video transmission：
720P@30fps
time-lapse：
200 ms (It depends on the actual shooting
environment and mobile devices)
Battery：
1S 7200mAh
