©2021 Swellpro Technology Co., Limited 43
Material
Waterproof polyester Oxford neoprene
3Axis Gimbal Thermal Camera (GC3-T)
Waterproof
IP67
Axis
3 axis(pitch,roll,yaw)
Pitching angle
-90°to 0°
Maximum control speed:
Pitching 60°/s
Weight
Approx. 450g
Size
110*100*115mm
Low Light Camera
Image Sensor:
1/2" 2M Starlight CMOS
Lens:
FOV: 66°
Burst
Shut/3/5/10pcs
Interval
Shut/1/3/5/10s
Video Resolution:
FHD: 1920*1080 30/60p | HD: 1280*720
120/60p
Max Video Stream:
64Mbps
Picture Format:
JPEG
Video Format:
MP4 / MOV
Support Memory Card:
Micro SD CARDS with a maximum capacity of
128GB, write speed ≥15 MB/s, and
transmission speed of Class 10 or above or
UHS-1 rating are supported
Working temperature
-10 to 40
IR Camera
Image Sensor:
Vanadium oxide uncooled infrared focal plane
detector
Lens:
19mm/25mm
Resolution@frame rate:
640*512 @30p/48p/50p
Palette:
White hot / black hot / Rainbow / Rainbow
high contrast / iron red / lava / Sky / medium
gray / grey red / purple orange / Special 1 /
warning red / ice fire / cyan red / special 2 /
gradient red / gradient green / gradient blue /
warning green / warning blue
Crosshairs
Show (default), hide, move
contrast ratio
Slider adjustment (0-255), default middle
value
Brightness:
Slider adjustment (0-511), default middle
value
DDE gear (image enhancement):
Off / On (default on)
Temperature measurement OSD on / off:
Off / On (the default displays the highest,
lowest, and center point temperatures)
Temperature measurement unit
Centigrade, Kelvin, Fahrenheit
Temperature measurement alarm
Off, low temperature alarm, high temperature
alarm, high and low temperature alarm
Low temperature alarm setting:
-20+150
