ENGLISH
RUBBER DIAPHRAGM WITH NOZZLE
COUNTERFLOW VALVE (110059)
ADDITIONAL EQUIPMENT (NOT INCLUDED)
Thisnozzleisusedforllingintocontainerswithasmall
opening.
It is absolutely necessary that all parts are put in the depic-
tedorder:
a) Disc with hole
b) Rubber diaphragm with three-sided notch
 c)Nozzle
d) Nut
Ifyourhoneycontainerstandslowerthanthellingma-
chineand/oryoutakebreaksduringthellingprocess,
honey can run back into the hose and this will lead
toairinthehoneywhenyoustartllingagain.Inthat
case,werecommendpurchasingthiscounterowvalve.
Thecounterowvalveisplacedonthepumphousing’s
inlettting.
a) Seal
b) Flow plate
c) Counter plate
