ENGLISH
DANA api MATIC 2000+ AND 3000
NO. DOC. NO. REV. NO. TITLE MATERIAL Qty. ITEM NO.
1 dt-004-011-2 00 Pump housing Rialan petp white 90x120x150 1 210038
2 dt-074-012-2 01 Pump cover TECAPET white FG 1 210036
3 dt-074-016 02 Drive shaft f/Crane seal A304-polished-h8 ø16x116 1 6074016
4 6002-B180_10_GL_1 Glas bearing Con no. 505170 1 505170
5 dt-004-010A 00 Fitting Stainless steel, Skal ø60x72 2 6004010A9F
6 dt-004-009 00 Accelerator shaft Stainless steel, Blank ø16 h9x65 1 60040099F
7 dt-074-017 02 Clutch ø15 Con no. 504500 1 6074017
8 O-ring ø37x2 Con no. 508037 2 508037
9 O-ring BS 1.5 Con no. 500212 2 500212
10 O-ring ø96x3 Con no. 508096 1 508096
11 Fitting spring acid-proof 5x5x40 Con no. 502705 1 701019D
12 Fitting spring acid-proof 5x5x16 Nav no. 701013 1 701013
13 dt-004-008 00 Module 4 ø59,2x47 12T DC 51,2 Træk Pom white 1 60040081F
14 dt-004-008 00 Module 4 ø59,2x47 12T DC 51,2 Medløb Pom white 1 60040081F
15 dt-074-024 01 Bearing housing f/Crane seal Stainless steel, 304 Skal ø65x46 1 60740249M0
16 O-ring ø30x1 Con no. 508030 1 508030
17 dt-074-028 03 Cover plate Stainless steel, 304 1mm B 1 6074028F
18 Lock ring ø 15 Nav no. 701059C 1 701059C
19 M5x35 submerged Allen A2 Stainless steel, 304 4 700329
20 M6x10 Pinol A2 Stainless steel, 304 1 700433
21 00 M5x10 Buttonhead A2 Stainless steel, 304 2 700223
22 Shaft seal ø16 Con no. 508301 1 508301
