Fitted Equipment
77
Symbol Function Description
Circulating Pump With this switch in the OFF POSITION the boiler will heat DOMESTIC HOT WATER ONLY.
On/Off
With this switch in the ON POSITION the boiler will heat DOMESTIC HOT WATER AND HEATING.
The circulation pump is then controlled by the Room Thermostat. The boiler then operates on Gas,
electric or both to maintain water temperature.
Gas Burner This LED indicates that the LPG Burner is ignited
Flame Indication
Fault Warning This LED indicates that the LPG Burner has not ignited. To Re-Set turn the Gas Burner Switch "Off",
wait for 30 seconds then Turn the Gas Burner Switch "On"
The Compact 3000 Boiler is fitted with 2 x
230 volt x 1kW Heating Elements. Each
element is controlled by a switch on the
Control Panel so it is possible to operate on
1kW or 2kW.
Note: Gas and Electrical power can be used
at the same time.
IMPORTANT CHECKS BEFORE
OPERATION:
• Check the level of fluid in the Header
Tank.
• Boiler must not be operated if fluid is
near Minimum Level! Level should always
be above minimum!
• The correct glycol mixture must be used
at all times of year! It not only prevents
freezing but also reduces corrosion within
the system.
• Check that the Butane/Propane gas
supply is correctly fitted via the proper
Gas Regulator.
• Propane Gas is recommended as it works
at lower ambient temperatures. Butane
ceases to operate at minus 2°C
• The Heating System can be used when
the Water Heater is empty.
• When using the system on Electrical
Power the vehicle should be on Mains
Hook Up to provide 12v power and
charge the battery.
• Operating without Hook Up may result in
a flat battery. Minimum requirement: 10v
If domestic hot water is not being used,
and there is a risk of frost, it should be
drained.
