Fitted Equipment
87
1. Set energy selector switch (A) to gas
2. Set rotary switch (B) to "MAX" position.
The ignition process is activated
automatically, accompanied by a ticking
sound approx. 30 sec. Upon successful
ignition, the display LED (C) "Gas" lights
yellow.The refrigerator is in function. Use
rotary switch (B) to regulate the temperature
in the main refrigerator compartment.
GAS FAULTS
In the event of a gas fault (e.g. gas cylinder
empty), the operating display (C) flashes
yellow.
Remedies:
Set the energy selector switch (A) to
position "OFF".
1. Is there any gas in the gas bottle?
2. Is the gas bottle valve open?
3. Is the on-board shut-off valve open?
4. Set the main switch (A) to "on"
The reignition starts again.
If after about 30 seconds the operating
display (C) starts flashing red again, the
gas fault has not been cleared (e.g. air in
the gas pipe).
5. Briefly switch the refrigerator off and then
on again using main switch (A).
To remove air from the gas pipes, repeat
this procedure 3-4 times.
If these actions do not help, please call an
authorised Dometic Service Centre.
Additional functions (RM 7XX5 L - models
only)
• Temperature setting display (D) with 4
LED to indicate the selected temperature
(MIN - MAX)
• LED - dimmer (E) for adjusting the
brightness of the display-LED (only
accessible when door opens)
Underneath the fascia is a knurled knob for
adjusting the brightness (see item E above)
Temperature setting cooling compartment
As shown, you are able to regulate the
temperature of the cooling compartment, if
necessary, by turning rotary knob (B) .
The cooling unit’s performance is influenced
by ambient temperatures.
Tip: Please select the medium setting for
ambient temperatures between +15°C and
+25°C. The unit operates within its optimum
performance range.
STORING FOOD
• Always store food in sealed containers,
aluminium foil or similar.
• Never put hot food into the refrigerator,
always let it cool down first.
