Swisson XMT-120A User Manual

22.2 Ground Topologies...............................................................................................................................................23
23 Safety Information........................................................................................................................................................24
24 Technical Data...............................................................................................................................................................24
1 Introduction
The XMT-120A and XMT-350 are the new generation of powerful DMX-512 measurement and test equipment for
architecture, entertainment, film and TV lighting and installations using DMX512. The versatile functions of the XMT-
120A simplify the debugging of lighting and installations, or any application where DMX is used to control lighting.
The unit can monitor DMX-512 signals as well as analyze and display them. The device can also generate DMX-512
signal and supports the control of more complex DMX-512 fixtures such as moving lights. The testing of RGB LED
lighting with many channels is easy to do with the XMT-120A or with the XMT-350. With additional features such as
cable tester, timing analysis, sequence editor, channel "tracer", dip-switch display and Min / Max display this device is
ideal for troubleshooting and resolving DMX-512 signal challenges and yet remains very simple to operate.
The XMT can be connected via USB to a PC. The Windows software allows managing the fixture library for intelligent
devices and updating the device's firmware.
2 Applications
• Concert Lighting
• Live Events
• Multimedia Shows
• Theater
• TV Sets
• Theme Parks
• Architectural Lighting
• Installation
3 Typical Application
4 Unpacking
XMT-120A: The following items are included:
• The device
• This user manual
XMT-350: The following items are included:
• The device
• This user manual
XMT-120A-SET: The following items are included:
• The device
• Nylon case
• 1 adapter XLR 3-pin to XLR 5-pin
• 1 adapter XLR 5-pin to XLR 3-pin
• This user manual
XMT-350-SET: The following items are included:
• The device
• Nylon case
• 1 adapter XLR 3-pin to XLR 5-pin
• 1 adapter XLR 5-pin to XLR 3-pin
• This user manual
4 PRELIMINARY

Swisson XMT-120A Specifications

General

Brand	Swisson
Model	XMT-120A
Category	Measuring Instruments
Language	English
