Align Mount horizontally
- Turn the Mount to face horizontally. This will put tension in
the Twist Strap and keep the Mount from turning any further.
If in the future the Mount sags, simply adjust to a new hole
on the Twist Strap.
Connect accessories
- Connect the PAS to the Quick Connect Handlebar Mount.
- To connect the waterproof connector, find the arrow on
each connector and align. Once aligned, push the connector
pair together until no colour is visible.
5
6
Connect motor
- Connect the motor to the Quick Connect Handlebar
Mount. Secure the motor wire to the fork with the cable ties
provided. Leave enough slack for the handlebars to turn.
- If the motor cable is not long enough, you may need an
extension cable.
Ensure the motor is fully connected – hear the “click”
- To connect the waterproof connector, align the arrows and
push together until the arrow on the motor wire connector
is touching the Mount connector. The photo below is not
properly connected.
- The photo below shows the motor connected correctly. You
will hear and feel a “click” once it is pushed in all the way.
7
8
BAD – not fully connected
GOOD – fully connected
