6.4 Brompton Front Luggage Block Adapter
(BRO BLOCK)
The Brompton Block Adapter allows the Power Pack to be
mounted directly to the frame.
These parts are included in the Bro Block Kit:
Cable ties x10
M5x12 Cap Screws x2
M5 Locking Washers x2
M5 Large Washers x2
Brompton Carrier Adaptor x1
Pedal Sensor Extension Cable x1
Fasten the mount to the front carrier mount attachment
at the front of the Brompton using the screws provided. Be
sure to assemble the screws in the order shown below.
Attach the Handlebar Bracket to the adapter.
Don’t use the spacers or the twist strap.
1
2
Assemble in
this order
