9.2 Motor Wheel isn’t spinning freely
First check that the brakes are properly adjusted and are
not touching the rim.
Next check if the motor casing is touching the forks. If it is,
you need to increase the gap between the forks to fix this.
The best way is to add a washer to the axle as shown below.
Alternatively, move the torque washer to the inside of the
forks and use in place of a new washer.
2
1
3
9.3 Pedal Sensor Magnet doesn’t fit my bike
If there isn’t enough space, remove the plastic hinge part and
mount the pedal sensor directly to the frame using the cable ties
provided.
The Pedal Sensor works with most bicycle types. The easiest
installation is to fit the magnet disk to the axle. This requires a
5mm gap between the frame and the pedal crank for the magnet
disk to fit.
Torque washer
Gap
Washer
