Connect your Pedal Sensor, Brake Sensors and Throttle to
the bracket. You will need to use extension cables to reach
the new position.
Shorten the motor cable by folding it back on itself and
securing it with a cable tie. Make the loop back the same
length as the length of the Brompton Block Adapter.
3
4
Use 2 extension cables to reach
handlebar addons e.g. Throttle
and Brake Sensors
Tie the cables to the
existing Brompton
cables to allow the
bike to fold
Use 1 extension cable
to reach the PAS
Thread the motor cable through the hole in the Brompton
Block Adapter to hide the excess cable.
You might find this step easier with the bracket removed
from the Block.
5
6
