Fit the inline brake sensor to the brake cable
- Thread the cable guide and inline sensor onto the bicycle
brake cable.
- The sensor connector should be pointing away from the
brake lever.
Reconnect the brake cable to your brakes
- If your cable is too short, use the spare provided to fit the
rear brake & use your rear brake cable to replace your front
brake cable.
2
1
Brake sensor goes
“in line” with the
brake cable, which
is fed through it
Cable guide keeps
it in line
Connect the brake sensor to the Quick Connect Mount
- Repeat for the other brake.
- Test by turning on the Power Pack and holding the (-)
button to activate the walk mode and check the brake
sensor stops the motor turning.
You can also assemble the brake sensors onto any point along
the brake cable.
3
