4.2 Manufacturer-specific Objects
Object 0x3000 : parameter
This object contains the manufacturer-specific parameters that can be used to set, operate and analyze the
inverter.
The object consists of 93 subnumbers. The subnumbers refer to the corresponding parameter number (for
details see manual SycoDrive).
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000
Parameter
Array
Subindex 0
Subindex 0 indicates the largest supported parameter number (Px).
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:00
nr_of_parameter
Variable
Unsigned8
ro
no
149
Subindex 1
Subindex 1 refers to the Rated frequency (P1). It is used to select the speed for the motor via the software
SycoDrive. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:01
f_soll
Variable
Unsigned16
ro
no
Subindex 8
Subindex 8 refers to the Speed display (P8). A display of speed in Hz or in rpm can be selected:
Value
Selection inverter
8005
hex
Hz
8006
hex
rpm
NOTE: See also Operating Manual Operating Software SycoDrive for HF Inverters e@syDrive 4624, 4625, 4626.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:08
drehzahl
Variable
Unsigned16
rw
no
Subindex a
Subindex a refers to the Rated frequency (P10). It is a display value. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:01
f_soll_akt
Variable
Unsigned16
ro
optional,
TPDO only
Subindex b
Subindex b refers to the Peak current (P11). It is a display value. The value is given from 5…240 in 0.1 A
steps; 240 equals 24 A.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:0b
I_linit_akt
Variable
Unsigned16
ro
optional,
TPDO only
