SycoTec easyDrive 4624 - Page 14

EN
14
Subindex d
Subindex d refers to the Actual frequency (P13). It is a display value. The value is given in Hz.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:0d
f_wr_ist
Variable
Unsigned16
ro
optional,
TPDO only
Subindex f
Subindex f refers to the Motor voltage (P15). It is a display value. The value is given from 0…650 in 0.1 V
steps; 650 equals 65 V.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:0f
V_motor
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 10
Subindex 10 refers to the DC link voltage (motor) (P16). It is a display value. The value is given from 0…750 in
0.1 V steps; 750 equals 75 V.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:10
u_zkreis
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 12
Subindex 12 refers to the Active current (P18), corrected by an offset of 25.000 mA. It is a display value. The
value is given in mA.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:12
I_mot
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 13
Subindex 13 refers to the Active power (P19). It is a display value. The value is given in W.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:13
P_wirk
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 14
Subindex 14 refers to the Motor code (P20). It is a display value.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:14
Motorcode
Variable
Unsigned16
ro
optional,
TPDO only
Subindex 15
Subindex 15 refers to the I²t load (P21). It is a display value. The value is given from 0…1000 in 0.1 % steps;
1000 equals 100 %.
Index
(hex)
Name
Object type
Data type
Access
PDO
mapping
Default
3000:15
I2tLoad
Variable
Unsigned16
ro
optional,
TPDO only
